| Model | HYCZLPG |
| Mass accuracy grade | 0.2 0.3 0.5 choose |
| Remp.accuracy | ±1°C |
| Repeatability | ±0.05% |
| Mpa | 4MPa |
| Nomianal diameter | 50mm |
| End connection | Flange（customizable）M32×1.5M32×1.5Nut（customized） |
| Fluid temperature | -200~200°C |
| Wetted parts | Stainless steel 316L |
| RH | =95%，non condensed |
| Loss of pressure | =0.2MPa |
| Ex-mark | II 2G Ex db [ib] IIC T6... T1 Gb(Transmitter) Ex ib IIC T6...T1 Gb(Sensor) |
| Operating voltage | AC85~265V，DC24V |
| Output signal | RS485；Modbus RTU；0~10KHz Sight flow pulse signal |
HYWL is a whole series industrial flowmeter which can supply all kinds of real material. Aluminum is the best one fit for petroleum production. In order to satisfy the user\'s demand. The designs of sensor are flexible. Normally the thread i
HYWL is a whole series industrial flowmeter which can supply all kinds of real material. Aluminum is the best one fit for petroleum production. In order to satisfy the user\'s demand. The designs of sensor are flexible. Normally the thread i
HYWL is a whole series industrial flowmeter which can supply all kinds of real material. Aluminum is the best one fit for petroleum production. In order to satisfy the user\'s demand. The designs of sensor are flexible. Normally the thread i
HYTCS series Positive Displacement Flow MeterAdvantage：Excellent step less adjusting mechanism allows a micro adjustment of the meter.High accuracy and repeatability over the widest range of flow;superior accuracy at constant flow.Low mainte
