Application
Oil companies: refineries, oil depots, gas stations and tankers
Airport: Airplane refueling
Port: Vessel Refueling
private oil transportation company
Advantage
Stepless adjusting mechanism allows a micro adjustment of the meter
Special designed manifold separates from measuring chamber for flexible installation
Low pressure loss
Simple construction of rotor blades for easy and low maintenance cost.
Wearing compensation to maintain a good accuracy all along the years.
Meter for viscous products up to 800Cst.
| Model | HYSM-50 | HYSM-80 |
| Size | 50mm/2" | 80mm/3" |
| Volume per Revolution | 0.4L/0.08US Gallons | 2.27L/0.5US Gallons |
| Max.Flow Rate | 24m³/H，400L/min | 80m³/H，1333L/min |
| Min.Flow Rate | 2.4m³/H，40L/min | 8m³/H，133.3L/min |
| US gallons | 10.5US Gallons | 36US Gallons |
| Accuracy | ±0.2% | |
| Repeatability | =0.05% | |
| Max.Operation Pressure | 8Bar/120PS/8.3kg/cm³ | 10Bar/150PSI/10.5kg/cm³ |
| Working Temperature range | -40°C~+60°C | |
| Max.Viscosity | 800cps/3850SSU | |
