| Adapt temperature | -40℃～+55℃ |
| Relative humidity | ≤95% |
| Air pressure | 86～106KPa |
| Voltage | AC220V±20% or AC380V±20% |
| Frequency | (50±1)HZ√ (60±1)HZ |
| Single range | 1～9999.99 ,1～999999.99(changeable) |
| Range of cumulative number of classes | 0~99999999 |
| Unit price setting range | 0～9999,0～999999(changeable) |
| Accumulative range | 0~9999999999.99 |
| Solenoid valve turn off setting range | 0~0.99L |
| Nozzle No. | From1~10（OEM） |
| Pump type | Suction pump/submersible pump |
The Number Of Digits Displayed On The Display
6 digits in the oil volume area, 6 digits in the amount area, and 4 digits in the unit price area (664)
8 digits in the oil volume area, 8 digits in the amount, and 6 digits in the unit price area (886)
Product Features
Electronic Calibration
Function of a Locking Pump
Fueling Time Limit Function
With Pump Lock Function
With Total Amount Stop Function
Optional Voice Reporting and Printout Functions
Can set the decimal point for the display, so it can be used in many countries with different currency rates.
Can choose between 7 digits for an electromagnetic counter or 9 digits for a mechanical totalizer counter.
Leaves communication ports open, so it can communicate with the gas station management system.
